FUEL SUPPLY PIPING, (3/3) (#75100-)
1
2
3
4
5
6
7
8
9
10
11
7
8
10
9
11
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 208-04-76170 | [1] | Bracket Komatsu China | |
| ["SN: 75100-UP"] | ||||
| 2. | 01010-81235 | [4] | Bolt Komatsu | 0.048 kg. |
| ["SN: 75100-UP"] analogs:["0101051235", "01010E1235", "801015136"] | ||||
| 3. | 01643-31232 | [4] | Washer Komatsu | 0.027 kg. |
| ["SN: 75100-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 4. | 600-311-9340 | [1] | Water Separator Komatsu | 0.000 kg. |
| ["SN: 75100-UP"] | ||||
| 5. | 01010-81030 | [4] | Bolt Komatsu OEM | 0.03 kg. |
| ["SN: 75100-UP"] analogs:["801015110", "M018011000306", "YM26116100302", "0101051030"] | ||||
| 6. | 01643-31032 | [4] | Washer Komatsu | 0.054 kg. |
| ["SN: 75100-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] | ||||
| 7. | 07270-00815 | [2] | Tube Komatsu China | |
| ["SN: 75100-UP"] | ||||
| 8. | 07285-00100 | [2] | Clip Komatsu | 1.3 kg. |
| ["SN: 75100-UP"] | ||||
| 9. | 02782-10516 | [2] | Elbow Komatsu | 0.24 kg. |
| ["SN: 75100-UP"] | ||||
| 10. | 02896-11015 | [2] | O-ring Komatsu | 0.21 kg. |
| ["SN: 75100-UP"] analogs:["21D0969770", "855051016"] | ||||
| 11. | 07002-12034 | [2] | O-ring Komatsu China | 0.94 kg. |
| ["SN: 75100-UP"] analogs:["0700002034", "0700202034", "0700012034"] | ||||
