TRAVEL MOTOR AND FINAL DRIVE, TRAVEL MOTOR (2/3) (#75001-) PC450LC-8R S/N 75001-UP Komatsu


OK request send
EXCAVATORS
PC450LC-8R S/N 75001-UP
TRAVEL MOTOR AND FINAL DRIVE
TRAVEL MOTOR AND FINAL DRIVE, TRAVEL MOTOR (1/3) (#75001-)
TRAVEL MOTOR AND FINAL DRIVE, TRAVEL MOTOR (1/3) (#75001-)
p003001
TRAVEL MOTOR AND FINAL DRIVE, TRAVEL MOTOR (3/3) (#75001-)
TRAVEL MOTOR AND FINAL DRIVE, TRAVEL MOTOR (3/3) (#75001-)
p003003
TRAVEL MOTOR AND FINAL DRIVE, FINAL DRIVE (#75001-75178)
TRAVEL MOTOR AND FINAL DRIVE, FINAL DRIVE (#75001-75178)
p003004
TRAVEL MOTOR AND FINAL DRIVE, FINAL DRIVE (#75179-)
TRAVEL MOTOR AND FINAL DRIVE, FINAL DRIVE (#75179-)
p003005

TRAVEL MOTOR AND FINAL DRIVE, TRAVEL MOTOR (2/3) (#75001-)

PC450LC-8R S/N 75001-UP
2
1
10
11
12
13
14
15
16
17
3
4
5
6
7
8
9
18
19
20
21
22
23
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
     208-27-00312   [2]   Final Drive Assembly Komatsu 750 kg.
    ["SN: 75179-UP"] analogs:["2082700242", "2082700241", "2082700240", "2082700243", "2082700311"] |$0.
     208-27-00311   [2]   Final Drive Assembly Komatsu 750 kg.
    ["SN: 75173-75178"] analogs:["2082700242", "2082700241", "2082700240", "2082700243", "2082700312"] |$1.
     208-27-00243   [2]   Final Drive Assembly Komatsu 750 kg.
    ["SN: 75001-75172", "SCC: A2"] analogs:["2082700242", "2082700241", "2082700240", "2082700312", "2082700311"] |$2.
        706-8J-01030   [1]   Motor Assembly Komatsu OEM 220 kg.
    ["SN: 75179-UP"] analogs:["7068J01011", "7068J01012", "7068J01031", "R7068J01031"] |$3.
        706-8J-01012   [1]   Motor Assembly Komatsu OEM 220 kg.
    ["SN: 75001-75178"] analogs:["7068J01011", "7068J01030", "7068J01031"] |$4.
1.   706-8J-41610   [1]   Shaft, Drive, Drive Komatsu 6.402 kg.
    ["SN: 75001-UP", "SCC: C2"]
2.   706-8J-41010   [1]   Bearing Komatsu 8.22 kg.
    ["SN: 75001-UP", "SCC: C2"]
3.   706-77-42890   [1]   Bearing Komatsu 1.185 kg.
    ["SN: 75001-UP", "SCC: C2"]
4.   706-8J-41810   [1]   Retainer Komatsu 1.09 kg.
    ["SN: 75001-UP", "SCC: C2"]
5.   706-8J-41660   [1]   Spacer Kit Komatsu 0.23 kg.
    ["SN: 75001-UP", "SCC: C2"]
6.   04064-06525   [1]   Ring, Snap, for Shaft Side Komatsu China 0.021 kg.
    ["SN: 75001-UP"]
7.   706-8J-41620   [1]   Seal, Oil Komatsu 0.15 kg.
    ["SN: 75001-UP"] analogs:["7068J42330"]
8.   706-8J-41820   [1]   Spacer Komatsu 0.12 kg.
    ["SN: 75001-UP"]
9.   04065-09030   [1]   Ring, Snap Komatsu 0.03 kg.
    ["SN: 75001-UP", "SCC: C2"] analogs:["2324013250", "R0406509030"]
10.   706-8J-41280   [1]   Shaft Komatsu OEM 1.91 kg.
    ["SN: 75001-UP", "SCC: C2"]
11.   706-8J-41270   [1]   Ring Komatsu 0.26 kg.
    ["SN: 75001-UP", "SCC: C2"]
12.   706-8J-41290   [1]   Spring Komatsu 0.38 kg.
    ["SN: 75001-UP", "SCC: C2"]
13.   706-8J-41260   [1]   Retainer Komatsu OEM 2.22 kg.
    ["SN: 75001-UP", "SCC: C2"]
14.   708-23-12350   [7]   Screw Komatsu 0.008 kg.
    ["SN: 75001-UP", "SCC: C2"]
15.   706-8J-42170   [7]   Piston Subassembly Komatsu OEM 0.000 kg.
    ["SN: 75179-UP", "SCC: C2"]
15.   706-8J-41161   [7]   Piston Subassembly Komatsu OEM 0.36 kg.
    ["SN: 75001-75178", "SCC: C2"]
16.   706-7K-91340   [5]   Plate Komatsu 1 kg.
    ["SN: 75001-UP", "SCC: C2"]
17.   706-7K-91350   [4]   Disc Komatsu 0.24 kg.
    ["SN: 75001-UP", "SCC: C2"]
18.   706-8J-91110   [1]   Piston Komatsu 9.802 kg.
    ["SN: 75001-UP", "SCC: C2"]
19.   07000-15230   [1]   O-ring Komatsu China 0.03 kg.
    ["SN: 75001-UP", "SCC: C2"] analogs:["0700005230"]
20.   07001-05230   [1]   Ring, Back-up Komatsu 0.016 kg.
    ["SN: 75001-UP", "SCC: C2"]
21.   708-8H-15220   [1]   O-ring Komatsu 0.025 kg.
    ["SN: 75001-UP", "SCC: C2"]
22.   706-8J-91120   [1]   Ring, Back-up Komatsu 0.02 kg.
    ["SN: 75001-UP", "SCC: C2"]
23.   706-8J-91130   [6]   Spring Komatsu 0.24 kg.
    ["SN: 75001-UP", "SCC: C2"]
