TRAVEL MOTOR AND FINAL DRIVE, FINAL DRIVE (#75179-) PC450LC-8R S/N 75001-UP Komatsu


OK request send
EXCAVATORS
PC450LC-8R S/N 75001-UP
TRAVEL MOTOR AND FINAL DRIVE
TRAVEL MOTOR AND FINAL DRIVE, FINAL DRIVE (#75001-75178)
TRAVEL MOTOR AND FINAL DRIVE, FINAL DRIVE (#75001-75178)
p003004
TRAVEL MOTOR AND FINAL DRIVE, TRAVEL MOTOR (3/3) (#75001-)
TRAVEL MOTOR AND FINAL DRIVE, TRAVEL MOTOR (3/3) (#75001-)
p003003
TRAVEL MOTOR AND FINAL DRIVE, TRAVEL MOTOR (2/3) (#75001-)
TRAVEL MOTOR AND FINAL DRIVE, TRAVEL MOTOR (2/3) (#75001-)
p003002

TRAVEL MOTOR AND FINAL DRIVE, FINAL DRIVE (#75179-)

PC450LC-8R S/N 75001-UP
17
7
2
1
2
5
4
3
38
36
37
4
15
16
24
40
34
39
18
25
8
9
35
6
22
23
21
20
19
21
12
11
10
12
13
14
30
31
32
27
26
29
33
28
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
     208-27-00312   [2]   Final Drive Assembly Komatsu 750 kg.
    ["SN: 75179-UP"] analogs:["2082700242", "2082700241", "2082700240", "2082700243", "2082700311"] |$0.
        208-27-00210   [1]   Seal Ring Assembly Komatsu OEM 3.46 kg.
    ["SN: 75001-UP"] |$1.
2.   425-33-11650   [2]   O-ring Komatsu 0.18 kg.
    ["SN: 75001-UP"]
   3.   208-27-71151   [1]   Gear Komatsu OEM 260 kg.
    ["SN: 75001-UP"] analogs:["2082771150"]
   4.   208-27-71210   [2]   Bearing Komatsu OEM 9.44 kg.
    ["SN: 75001-UP"]
   5.   208-27-71310   [1]   Collar Komatsu 2.26 kg.
    ["SN: 75001-UP"]
   6.   208-27-71270   [1]   Lock Komatsu 0.05 kg.
    ["SN: 75001-UP"]
   7.   208-27-71260   [1]   Lock Komatsu 7.17 kg.
    ["SN: 75001-UP"]
   8.   01010-81020   [2]   Bolt Komatsu 0.161 kg.
    ["SN: 75001-UP"] analogs:["801014093", "0101051020", "801015108"]
   9.   208-27-71170   [1]   Carrier Komatsu OEM 55 kg.
    ["SN: 75001-UP"]
   10.   208-27-71140   [4]   Gear Komatsu OEM 11.85 kg.
    ["SN: 75001-UP"]
   11.   208-27-71230   [4]   Bearing Komatsu OEM 0.64 kg.
    ["SN: 75001-UP"]
   12.   21M-27-11260   [8]   Washer, Thrust Komatsu OEM 0.24 kg.
    ["SN: 75001-UP"]
   13.   208-27-71250   [4]   Pin Komatsu OEM 2.16 kg.
    ["SN: 75001-UP"]
   14.   20Y-27-21290   [4]   Pin Komatsu OEM 0.03 kg.
    ["SN: 75001-UP"]
   15.   207-27-52270   [1]   Spacer Komatsu OEM 0.089 kg.
    ["SN: 75001-UP"]
   16.   208-27-71130   [1]   Gear Komatsu OEM 4.1 kg.
    ["SN: 75001-UP"]
   17.   208-27-71290   [1]   Spacer Komatsu OEM 0.4 kg.
    ["SN: 75001-UP"]
   18.   208-27-71160   [1]   Carrier Komatsu OEM 15.4 kg.
    ["SN: 75001-UP"]
   19.   208-27-71120   [3]   Gear Komatsu OEM 15.3 kg.
    ["SN: 75001-UP"]
   20.   208-27-71220   [3]   Bearing Komatsu OEM 0.22 kg.
    ["SN: 75001-UP"]
   21.   20Y-27-21250   [6]   Washer, Thrust Komatsu China 0.03 kg.
    ["SN: 75001-UP"]
   22.   21M-27-11240   [3]   Pin Komatsu OEM 1.17 kg.
    ["SN: 75001-UP"]
   23.   20Y-27-21280   [3]   Pin Komatsu China 0.01 kg.
    ["SN: 75001-UP"]
   24.   208-27-71112   [1]   Shaft Komatsu OEM 2.7 kg.
    ["SN: 75001-UP"] analogs:["2082771111"]
   25.   20Y-27-11250   [1]   Spacer Komatsu OEM 0.044 kg.
    ["SN: 75001-UP"] analogs:["2052771570"]
   26.   04260-01905   [1]   Ball Komatsu OEM 0.029 kg.
    ["SN: 75001-UP"]
   27.   208-27-71651   [1]   Cover Komatsu 0.000 kg.
    ["SN: 75173-UP"]
   28.   208-27-71660   [1]   O-ring Komatsu 0.000 kg.
    ["SN: 75173-UP"]
   29.   01010-81235   [16]   Bolt Komatsu 0.048 kg.
    ["SN: 75001-UP"] analogs:["0101051235", "01010E1235", "801015136"]
   30.   01643-31232   [16]   Washer Komatsu 0.027 kg.
    ["SN: 75001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
   31.   07049-01215   [2]   Plug Komatsu 0.001 kg.
    ["SN: 75001-UP"]
   32.   20Y-27-31190   [3]   Plug Komatsu 0.07 kg.
    ["SN: 75001-UP"]
   33.   07002-12434   [3]   O-ring Komatsu China 0.01 kg.
    ["SN: 75001-UP"] analogs:["0700202434", "0700213434"]
   34.   208-27-61210   [1]   Sprocket Komatsu China 60 kg.
    ["SN: 75001-UP"]
   35.   207-27-51311   [26]   Bolt Komatsu China 0.222 kg.
    ["SN: 75001-UP"] analogs:["2072751310", "20727K1120", "20727K1130"]
36.   01011-82000   [48]   Bolt Komatsu 0.31 kg.
    ["SN: 75001-UP"] analogs:["0101162000", "801015657"]
37.   01643-32060   [48]   Washer Komatsu China 0.044 kg.
    ["SN: 75001-UP"] analogs:["802170007", "0164322045", "0164302045"]
38.   208-30-71241   [2]   Cover Komatsu 25.81 kg.
    ["SN: 75001-UP"]
39.   01010-81640   [12]   Bolt Komatsu 0.264 kg.
    ["SN: 75001-UP"] analogs:["0101061640", "801015186", "0101031640", "0101051640"]
40.   01643-31645   [12]   Washer Komatsu 0.072 kg.
    ["SN: 75001-UP"] analogs:["802170005", "0164301645"]
