RIGHT SIDE STEP, (#30246-)
8
4
7
1
5
6
2
3
9
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 21N-53-32940 | [1] | Step Komatsu China | |
| ["SN: 30158-UP"] | ||||
| 2. | 01010-81240 | [8] | Bolt Komatsu | 0.052 kg. |
| ["SN: 30158-UP"] analogs:["801015573", "0101051240"] | ||||
| 3. | 01643-31232 | [8] | Washer Komatsu | 0.027 kg. |
| ["SN: 30158-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 4. | 21N-53-32930 | [1] | Handrail Komatsu China | |
| ["SN: 30158-UP"] | ||||
| 5. | 01010-81230 | [12] | Bolt Komatsu | 0.043 kg. |
| ["SN: 30158-UP"] analogs:["0101051230", "01010B1230"] | ||||
| 9. | 07049-01215 | [8] | Plug Komatsu | 0.001 kg. |
| ["SN: 30246-UP"] | ||||
