AIR CLEANER (#65001-)
7
4
1
1
2
8
9
32
32
31
3
29
34
33
5
5
6
6
6
5
26
10
27
27
17
20
21
22
19
18
23
25
24
11
14
15
16
13
12
32
32
32
32
32
32
38
35
32
28
40
39
30
37
36
34
33
41
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 6151-11-9970 | [2] | Band Assembly Komatsu | 0.83 kg. |
| ["SN: 65001-UP"] | ||||
| 2. | 6643-11-4641 | [2] | Bolt Komatsu | 0.09 kg. |
| ["SN: 65001-UP"] | ||||
| 3. | 21M-01-21170 | [1] | Seal Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 4. | 21M-01-15211 | [1] | Bracket Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 5. | 01010-81230 | [6] | Bolt Komatsu | 0.043 kg. |
| ["SN: 65001-UP"] analogs:["0101051230", "01010B1230"] | ||||
| 6. | 01643-31232 | [6] | Washer Komatsu | 0.027 kg. |
| ["SN: 65001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 7. | 21M-01-21120 | [1] | Hose Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 8. | 07289-00170 | [1] | Clamp, Hose Komatsu | 0.09 kg. |
| ["SN: 65001-UP"] | ||||
| 9. | 07289-00160 | [1] | Clamp, Hose Komatsu | 0.084 kg. |
| ["SN: 65001-UP"] | ||||
| 10. | 21M-01-21110 | [1] | Tube Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 11. | 21M-01-21130 | [1] | Bracket Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 13. | 175-54-34170 | [2] | Washer Komatsu | 0.03 kg. |
| ["SN: 65001-UP"] | ||||
| 14. | 428-62-14640 | [1] | Clip Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 16. | 01597-01211 | [2] | Nut Komatsu | 0.016 kg. |
| ["SN: 65001-UP"] | ||||
| 17. | 21M-01-31110 | [1] | Bracket Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 18. | 01010-81235 | [2] | Bolt Komatsu | 0.048 kg. |
| ["SN: 65001-UP"] analogs:["0101051235", "01010E1235", "801015136"] | ||||
| 23. | 21M-01-21150 | [1] | Bracket Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 24. | 01010-81240 | [2] | Bolt Komatsu | 0.052 kg. |
| ["SN: 65001-UP"] analogs:["801015573", "0101051240"] | ||||
| 26. | 21M-01-21160 | [1] | Hose Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 28. | 7861-93-1422 | [1] | Sensor Komatsu | 0.000 kg. |
| ["SN: 65047-UP"] | ||||
| 28. | 7861-93-1421 | [1] | Sensor Komatsu | 0.1 kg. |
| ["SN: 65001-65046"] analogs:["7861931420", "20Y0642910"] | ||||
| 29. | 08672-01000 | [1] | Indicator Komatsu | 0.072 kg. |
| ["SN: 65001-UP"] | ||||
| 30. | 08671-50186 | [1] | Hose Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 31. | 08671-60140 | [1] | Hose Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 32. | 04434-51412 | [9] | Clip Komatsu | 0.02 kg. |
| ["SN: 65001-UP"] | ||||
| 35. | 22S-62-26210 | [1] | Spacer Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 36. | 01011-81200 | [1] | Bolt Komatsu | 0.104 kg. |
| ["SN: 65001-UP"] analogs:["801015583", "0101151200"] | ||||
| 38. | 208-01-62112 | [1] | Bracket Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 39. | 01010-81220 | [2] | Bolt Komatsu | 0.032 kg. |
| ["SN: 65001-UP"] analogs:["0101051220"] | ||||
| 41. | 21M-01-21950 | [1] | Cover Komatsu | 0.5 kg. |
| ["SN: 65001-UP"] | ||||
