POWER TAKEOFF, OIL CHECK GAUGE (#65001-)

PC600LC-8E0 S/N 65001-UP
1
3
2
4
6
7
11
8
5
9
10
12
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
1.   21M-38-21310   [1]   Tube Komatsu China
    ["SN: 65001-UP"]
2.   07000-E3028   [1]   O-ring Komatsu 0.002 kg.
    ["SN: 65001-UP"] analogs:["0700033028"]
3.   01010-81040   [2]   Bolt Komatsu 0.288 kg.
    ["SN: 65001-UP"] analogs:["0101051040", "R0101081040"]
4.   01643-31032   [2]   Washer Komatsu 0.054 kg.
    ["SN: 65001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
5.   21M-38-31120   [1]   Bracket Komatsu China
    ["SN: 65001-UP"]
6.   01010-81240   [2]   Bolt Komatsu 0.052 kg.
    ["SN: 65001-UP"] analogs:["801015573", "0101051240"]
7.   01643-31232   [2]   Washer Komatsu 0.027 kg.
    ["SN: 65001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
8.   21M-38-11331   [1]   Gauge Komatsu China
    ["SN: 65001-UP"]
9.   07283-22746   [1]   Clip Komatsu 0.094 kg.
    ["SN: 65001-UP"]
10.   01597-01009   [2]   Nut Komatsu 0.011 kg.
    ["SN: 65001-UP"]
12.   21M-62-31240   [-1]   Bracket Komatsu China
    ["SN: UP"]
     21M-62-31290   [-1]   Bracket Komatsu China
    ["SN: UP"] |$12.
