REVOLVING FRAME, FRAME (#65001-)
3
2
5
4
1
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 21M-46-31160 | [1] | Frame Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 2. | 205-30-71181 | [1] | Cover Komatsu | 1 kg. |
| ["SN: 65001-UP"] | ||||
| 3. | 205-30-71191 | [1] | Gasket Komatsu | 0.022 kg. |
| ["SN: 65001-UP"] | ||||
| 4. | 01010-81230 | [2] | Bolt Komatsu | 0.043 kg. |
| ["SN: 65001-UP"] analogs:["0101051230", "01010B1230"] | ||||
| 5. | 01643-31232 | [2] | Washer Komatsu | 0.027 kg. |
| ["SN: 65001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
