SWIVEL JOINT, RELATED PARTS (#65001-) PC600LC-8E0 S/N 65001-UP Komatsu


OK request send
EXCAVATORS
PC600LC-8E0 S/N 65001-UP
SWIVEL JOINT
SWIVEL JOINT, INNER PARTS, SWIVEL JOINT (#65001-)
SWIVEL JOINT, INNER PARTS, SWIVEL JOINT (#65001-)
n005001

SWIVEL JOINT, RELATED PARTS (#65001-)

PC600LC-8E0 S/N 65001-UP
35
3
3
30
31
34
29
8
13
12
15
35
33
32
9
22
20
21
16
24
6
19
18
7
9
9
25
11
17
10
14
28
1
26
2
27
4
5
26
25
23
8
9
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
1.   21M-62-14631   [1]   Tee Komatsu China
    ["SN: 65001-UP"]
2.   07002-12434   [1]   O-ring Komatsu China 0.01 kg.
    ["SN: 65001-UP"] analogs:["0700202434", "0700213434"]
3.   02896-11018   [2]   O-ring Komatsu 0.24 kg.
    ["SN: 65001-UP"] analogs:["855051018", "R0289611018"]
4.   201-62-71810   [1]   Joint Komatsu 0.17 kg.
    ["SN: 65001-UP"]
6.   21W-62-42630   [1]   Tee Komatsu 0.15 kg.
    ["SN: 65001-UP"]
7.   07002-11423   [1]   O-ring Komatsu China 0.001 kg.
    ["SN: 65001-UP"] analogs:["0700201423"]
8.   02896-11009   [2]   O-ring Komatsu China 0.01 kg.
    ["SN: 65001-UP"] analogs:["R0289611009", "0286911009"]
9.   07371-31049   [8]   Flange, Split Komatsu 0.12 kg.
    ["SN: 65001-UP"] analogs:["0737121049"]
10.   07372-21035   [16]   Bolt Komatsu 0.033 kg.
    ["SN: 65001-UP"]
11.   01643-51032   [16]   Washer Komatsu 0.17 kg.
    ["SN: 65001-UP"] analogs:["R0164351032"]
12.   02782-10516   [1]   Elbow Komatsu 0.24 kg.
    ["SN: 65001-UP"]
13.   07002-12034   [1]   O-ring Komatsu China 0.94 kg.
    ["SN: 65001-UP"] analogs:["0700002034", "0700202034", "0700012034"]
14.   02896-11015   [1]   O-ring Komatsu 0.21 kg.
    ["SN: 65001-UP"] analogs:["21D0969770", "855051016"]
15.   20U-62-46570   [1]   Elbow Komatsu 0.4 kg.
    ["SN: 65001-UP"]
18.   21M-62-31341   [1]   Elbow Komatsu China
    ["SN: 65001-UP"]
20.   11Y-62-12510   [1]   Elbow Komatsu 0.2 kg.
    ["SN: 65001-UP"]
23.   209-62-14430   [1]   Plate Komatsu 0.33 kg.
    ["SN: 65001-UP"]
24.   201-60-11230   [1]   Pin Komatsu China
    ["SN: 65001-UP"] analogs:["500327265", "PZF500327265"]
25.   01641-21626   [2]   Washer Komatsu 0.01 kg.
    ["SN: 65001-UP"] analogs:["0164101626"]
26.   04050-14025   [2]   Pin, Cotter Komatsu 0.003 kg.
    ["SN: 65001-UP"] analogs:["0405004025"]
27.   01010-81235   [4]   Bolt Komatsu 0.048 kg.
    ["SN: 65001-UP"] analogs:["0101051235", "01010E1235", "801015136"]
28.   01643-31232   [4]   Washer Komatsu 0.027 kg.
    ["SN: 65001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
29.   02762-00507   [-1]   Hose, Face Seal Type Komatsu China 0.749 kg.
    ["SN: UP"]
30.   02762-005A5   [-1]   Hose Komatsu China 0.75 kg.
    ["SN: UP"]
31.   07098-01011   [-1]   Hose, Flange Type Komatsu China 3.61 kg.
    ["SN: UP"]
32.   207-62-61590   [-1]   Hose Komatsu OEM 3.3 kg.
    ["SN: UP"]
33.   02760-00331   [-1]   Hose, Face Seal Type Komatsu China 0.812 kg.
    ["SN: UP"]
34.   02762-00332   [-1]   Hose Komatsu 0.85 kg.
    ["SN: UP"]
35.   02764-00632   [-1]   Hose Komatsu China 2.664 kg.
    ["SN: UP"]
