COUPLING, OIL CHECK GAUGE (#65001-)
1
5
2
3
6
7
9
10
11
4
8
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 209-01-42170 | [1] | Gauge Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 2. | 209-01-42182 | [1] | Tube Komatsu China | |
| ["SN: 65001-UP"] analogs:["2090142182XC"] | ||||
| 3. | 01010-81065 | [2] | Bolt Komatsu | 0.051 kg. |
| ["SN: 65001-UP"] analogs:["0101051065"] | ||||
| 4. | 01643-31032 | [2] | Washer Komatsu | 0.054 kg. |
| ["SN: 65001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] | ||||
| 5. | 07000-E3028 | [1] | O-ring Komatsu | 0.002 kg. |
| ["SN: 65001-UP"] analogs:["0700033028"] | ||||
| 6. | 209-01-42192 | [1] | Bracket Komatsu China | |
| ["SN: 65001-UP"] analogs:["2090142192XC"] | ||||
| 7. | 01010-81230 | [2] | Bolt Komatsu | 0.043 kg. |
| ["SN: 65001-UP"] analogs:["0101051230", "01010B1230"] | ||||
| 8. | 01643-31232 | [2] | Washer Komatsu | 0.027 kg. |
| ["SN: 65001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 9. | 07283-32738 | [1] | Clip, Pipe Komatsu | 0.084 kg. |
| ["SN: 65001-UP"] | ||||
| 10. | 01597-01009 | [2] | Nut Komatsu | 0.011 kg. |
| ["SN: 65001-UP"] | ||||
