CYLINDER HEAD
1
2
3
3
4
5
6
7
8
8
9
9
10
10
11
11
12
12
13
14
15
16
17
18
18
19
19
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | YM719660-11700 | [1] | CYLINDER HEAD A. Komatsu China | |
| ["SN: 02519-UP"] analogs:["YMR000653", "YM11962911700"] | ||||
| 2. | YM121850-11860 | [2] | PLUG Komatsu | 0.01 kg. |
| ["SN: 02519-UP"] analogs:["YMR000071"] | ||||
| 3. | YM128272-11170 | [6] | GUIDE Komatsu China | |
| ["SN: 02519-UP"] analogs:["YMR000665", "YM11962011801", "YM12406011170"] | ||||
| 4. | YM119620-11100 | [3] | VALVE,INTAKE Komatsu China | |
| ["SN: 02519-UP"] analogs:["YMR000655"] | ||||
| 5. | YM119620-11110 | [3] | VALVE,EXHAUST Komatsu China | |
| ["SN: 02519-UP"] analogs:["YMR000656"] | ||||
| 6. | YM124160-11340 | [3] | SEAT,INTAKE Komatsu | 0.001 kg. |
| ["SN: 02519-UP"] analogs:["YM12495011340"] | ||||
| 7. | YM124950-11340 | [3] | SEAT,EXHAUST Komatsu | 0.001 kg. |
| ["SN: 02519-UP"] analogs:["YM12416011340"] | ||||
| 8. | YM119620-11120 | [6] | SPRING Komatsu China | |
| ["SN: 02519-UP"] analogs:["YMR000657"] | ||||
| 9. | YM119620-11180 | [6] | SEAT,SPRING Komatsu China | |
| ["SN: 02519-UP"] analogs:["YMR000658"] | ||||
| 10. | YM101158-11190 | [6] | COTTER,VALVE Komatsu | 0.096 kg. |
| ["SN: 02519-UP"] analogs:["YM27310070001"] | ||||
| 11. | YM104211-11370 | [6] | CAP Komatsu | 0.002 kg. |
| ["SN: 02519-UP"] | ||||
| 12. | YM27241-400000 | [2] | PLUG Komatsu | 0.03 kg. |
| ["SN: 02519-UP"] analogs:["YMR000437"] | ||||
| 13. | YM27221-050080 | [1] | PLUG Komatsu China | |
| ["SN: 02519-UP"] analogs:["YMR000654"] | ||||
| 14. | YM119656-11410 | [3] | INSERT Komatsu China | |
| ["SN: 02519-UP"] analogs:["YM11960011410", "YM11962011420"] | ||||
| 15. | YM22351-060012 | [2] | PIN,SPRING Komatsu | 0.002 kg. |
| ["SN: 02519-UP"] | ||||
| 16. | YM119610-01340 | [1] | GASKET,HEAD (KIT) Komatsu | 0.132 kg. |
| ["SN: 02519-UP"] | ||||
| 17. | YM119620-01200 | [14] | BOLT Komatsu China | |
| ["SN: 02519-UP"] analogs:["YMR000615"] | ||||
| 18. | YM119260-07900 | [2] | HOOK Komatsu China | |
| ["SN: 02519-UP"] analogs:["YMR002134", "YM11962007900"] | ||||
| 19. | YM26106-080142 | [3] | BOLT Komatsu | 0.01 kg. |
| ["SN: 02519-UP"] | ||||
