FUEL TANK(#10043-) D575A-2 S/N 10001-UP Komatsu


OK request send
BULLDOZERS
D575A-2 S/N 10001-UP
FUEL TANK AND RELATED PARTS
FUEL TANK(#10001-10042)
FUEL TANK(#10001-10042)
090010
FUEL TANK (SUPER DOZER)
FUEL TANK (SUPER DOZER)
090030
FUEL SHUT OFF CONTROL (1/2)(#10038-)
FUEL SHUT OFF CONTROL (1/2)(#10038-)
090040
FUEL SHUT OFF CONTROL (2/2)(#10038-)
FUEL SHUT OFF CONTROL (2/2)(#10038-)
090050

FUEL TANK(#10043-)

D575A-2 S/N 10001-UP
1
2
3
4
5
6
7
8
9
10
10
11
11
12
12
13
13
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
29
30
30
31
31
32
32
33
33
34
34
35
36
37
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
1.   19M-04-21110   [1]   TANK Komatsu China
    ["SN: 10040-UP"]
2.   195-04-31160   [1]   COVER Komatsu China
    ["SN: 10043-UP"]
3.   07000-12115   [1]   O-RING Komatsu OEM 0.004 kg.
    ["SN: 10040-UP"] analogs:["0700002115"]
4.   01010-80825   [6]   BOLT Komatsu 0.015 kg.
    ["SN: 10043-UP"] analogs:["0101050825", "01010D0825", "801015087"]
5.   01602-20825   [6]   WASHER Komatsu 0.004 kg.
    ["SN: 10043-UP"] analogs:["0160200825", "0231011020", "6124613790"]
6.   07056-18416   [1]   STRAINER Komatsu 0.2 kg.
    ["SN: 10001-UP"] analogs:["0705608420", "1310441120"]
7.   07057-04087   [1]   RING,SNAP Komatsu 0.03 kg.
    ["SN: 10001-UP"]
8.   19M-04-11410   [1]   GAUGE Komatsu China
    ["SN: 10001-UP"]
9.   19M-04-11471   [1]   TUBE Komatsu China
    ["SN: 10043-UP"] analogs:["19M0411470"]
10.   07000-13028   [2]   O-RING Komatsu China 0.001 kg.
    ["SN: 10001-UP"] analogs:["0700003028"]
11.   01010-81050   [4]   BOLT Komatsu 0.038 kg.
    ["SN: 10001-UP"] analogs:["801015559", "0101051050"]
12.   01643-31032   [4]   WASHER Komatsu 0.054 kg.
    ["SN: 10001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
13.   01010-81020   [4]   BOLT Komatsu 0.161 kg.
    ["SN: 10001-UP"] analogs:["801014093", "0101051020", "801015108"]
15.   19M-04-11461   [1]   TUBE Komatsu China
    ["SN: 10001-UP"] analogs:["19M0411460"]
16.   07230-20522   [1]   UNION Komatsu 0.152 kg.
    ["SN: 10001-UP"] analogs:["0723010522", "2036251230"]
17.   07002-02434   [1]   O-RING Komatsu China 0.01 kg.
    ["SN: 10001-UP"] analogs:["0700212434", "0700213434"]
18.   195-04-11230   [1]   JOINT Komatsu China
    ["SN: 10001-UP"]
19.   07000-13035   [2]   O-RING Komatsu China 0.03 kg.
    ["SN: 10001-UP"] analogs:["0700003035"]
20.   195-04-11280   [1]   BOLT Komatsu 0.212 kg.
    ["SN: 10001-UP"]
21.   07700-40460   [1]   VALVE Komatsu 0.228 kg.
    ["SN: 10001-UP"] analogs:["0770020504"]
22.   07238-10522   [1]   CONNECTOR Komatsu 0.126 kg.
    ["SN: 10003-UP"]
23.   566-98-15100   [1]   VENT ASS'Y Komatsu 1 kg.
    ["SN: 10001-UP"]
24.   7861-92-4930   [1]   SENSOR,FUEL LEVEL Komatsu 0.74 kg.
    ["SN: 10012-UP"]
25.   07000-12085   [1]   O-RING Komatsu China 0.03 kg.
    ["SN: 10012-UP"] analogs:["0700002085", "YM24321000850", "R0700012085"]
28.   08193-21012   [1]   CLIP Komatsu 0.011 kg.
    ["SN: 10043-UP"]
29.   01010-81220   [2]   BOLT Komatsu 0.032 kg.
    ["SN: 10012-UP"] analogs:["0101051220"]
30.   01643-31232   [2]   WASHER Komatsu 0.027 kg.
    ["SN: 10012-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
31.   19M-04-11490   [2]   UNION Komatsu China
    ["SN: 10001-UP"]
32.   07002-13334   [2]   O-RING Komatsu China 0.025 kg.
    ["SN: 10001-UP"] analogs:["0700203334"]
33.   19M-04-11540   [2]   VALVE Komatsu China
    ["SN: 10043-UP"]
34.   582-35-11410   [2]   ELBOW Komatsu China
    ["SN: 10001-UP"]
35.   07235-10210   [1]   ELBOW Komatsu 0.083 kg.
    ["SN: 10001-UP"]
36.   07002-11423   [1]   O-RING Komatsu China 0.001 kg.
    ["SN: 10001-UP"] analogs:["0700201423"]
37.   08028-56055   [1]   CABLE Komatsu 0.68 kg.
    ["SN: 10012-UP"]
