HYDRAULIC OIL COOLER(#1001-)
1
2
3
4
5
5
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
18
18
19
19
20
20
21
21
22
23
24
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 154-969-3412 | [1] | OIL COOLER Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 2. | 154-969-3421 | [1] | BRACKET Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 3. | 01010-81240 | [4] | BOLT Komatsu | 0.052 kg. |
| ["SN: 1001-UP"] analogs:["801015573", "0101051240"] | ||||
| 4. | 01643-31232 | [4] | WASHER Komatsu | 0.027 kg. |
| ["SN: 1001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 5. | 195-54-42550 | [4] | CUSHION Komatsu | 0.05 kg. |
| ["SN: 1001-UP"] | ||||
| 6. | 17A-04-11191 | [2] | PLATE Komatsu | 0.58 kg. |
| ["SN: 1001-UP"] | ||||
| 7. | 195-54-42560 | [2] | BOSS Komatsu | 0.163 kg. |
| ["SN: 1001-UP"] | ||||
| 8. | 01010-81685 | [2] | BOLT Komatsu | 0.165 kg. |
| ["SN: 1001-UP"] analogs:["0101051685", "0101031685", "0101061685"] | ||||
| 9. | 01643-31645 | [2] | WASHER Komatsu | 0.072 kg. |
| ["SN: 1001-UP"] analogs:["802170005", "0164301645"] | ||||
| 10. | 154-969-3481 | [2] | BRACKET Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 13. | 154-969-3470 | [2] | PLATE Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 14. | 01010-81230 | [4] | BOLT Komatsu | 0.043 kg. |
| ["SN: 1001-UP"] analogs:["0101051230", "01010B1230"] | ||||
| 16. | 154-969-3490 | [2] | BRACKET Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 19. | 17A-03-11411 | [2] | PLATE Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 22. | 154-969-3170 | [1] | COVER Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 23. | 01010-81225 | [2] | BOLT Komatsu | 0.074 kg. |
| ["SN: 1001-UP"] analogs:["01010B1225", "0101051225", "0101051222", "R0101081225"] | ||||
