ROTOR LIFT LINE (ROTOR LIFT CYLINDER TUBE)(#1001-)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
39
39
39
40
40
40
40
40
40
40
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 154-61-73850 | [1] | TUBE Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 2. | 07000-13030 | [1] | O-RING Komatsu | 0.001 kg. |
| ["SN: 1001-UP"] analogs:["37B0915217", "21D0969930"] | ||||
| 3. | 07372-21045 | [2] | BOLT Komatsu | 0.039 kg. |
| ["SN: 1001-UP"] | ||||
| 4. | 01643-51032 | [2] | WASHER Komatsu | 0.17 kg. |
| ["SN: 1001-UP"] analogs:["R0164351032"] | ||||
| 5. | 07372-21060 | [2] | BOLT Komatsu | 0.045 kg. |
| ["SN: 1001-UP"] analogs:["0737251060"] | ||||
| 7. | 195-49-13850 | [1] | CLIP Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 8. | 01010-81230 | [1] | BOLT Komatsu | 0.043 kg. |
| ["SN: 1001-UP"] analogs:["0101051230", "01010B1230"] | ||||
| 9. | 01643-31232 | [1] | WASHER Komatsu | 0.027 kg. |
| ["SN: 1001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 10. | 154-61-73860 | [1] | TUBE Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 19. | 154-61-73590 | [1] | BRACKET Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 22. | 07283-32738 | [2] | CLIP Komatsu | 0.084 kg. |
| ["SN: 1001-UP"] | ||||
| 23. | 01597-01009 | [4] | NUT Komatsu | 0.011 kg. |
| ["SN: 1001-UP"] | ||||
| 24. | 01643-31032 | [4] | WASHER Komatsu | 0.054 kg. |
| ["SN: 1001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] | ||||
| 25. | 154-61-73830 | [1] | TUBE Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 29. | 154-61-73840 | [1] | TUBE Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 33. | 154-61-73740 | [1] | BRACKET Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 39. | 154-969-3860 | [4] | HOSE Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 40. | 02896-11018 | [8] | O-RING Komatsu | 0.24 kg. |
| ["SN: 1001-UP"] analogs:["855051018", "R0289611018"] | ||||
