FAN DRIVE LINE(#1001-) D85MS-15 S/N 1001-1005 Komatsu


OK request send
CRAWLER LOADERS
D85MS-15 S/N 1001-1005
HYDRAULIC SYSTEM
ROTOR TILT LINE(#1005-)
ROTOR TILT LINE(#1005-)
180120
ROTOR TILT LINE(#1001-1004)
ROTOR TILT LINE(#1001-1004)
180110
ROTOR LIFT LINE (COVER AND BRACKET)(#1001-)
ROTOR LIFT LINE (COVER AND BRACKET)(#1001-)
180100
P.P.C. PIPING CLAMP(#1001-1004)
P.P.C. PIPING CLAMP(#1001-1004)
180140
P.P.C. PIPING(#1005-)
P.P.C. PIPING(#1005-)
180150

FAN DRIVE LINE(#1001-)

D85MS-15 S/N 1001-1005
1
1
2
2
2
2
3
3
4
4
5
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
28
29
30
30
30
30
30
30
31
31
31
32
32
32
33
33
33
34
35
35
35
35
36
36
37
37
38
38
39
39
40
41
42
42
43
43
44
45
46
47
48
49
50
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
1.   154-03-72520   [1]   HOSE Komatsu 1.7 kg.
    ["SN: 1001-UP"]
2.   07094-10417   [4]   CLAMP Komatsu China
    ["SN: 1001-UP"]
3.   07095-00420   [2]   CUSHION Komatsu 0.046 kg.
    ["SN: 1001-UP"]
4.   01010-81265   [2]   BOLT Komatsu 0.074 kg.
    ["SN: 1001-UP"] analogs:["0101051265"]
5.   01643-31232   [2]   WASHER Komatsu 0.027 kg.
    ["SN: 1001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
6.   154-61-71141   [1]   BRACKET Komatsu China
    ["SN: 1001-UP"]
7.   01010-81230   [2]   BOLT Komatsu 0.043 kg.
    ["SN: 1001-UP"] analogs:["0101051230", "01010B1230"]
9.   702-21-09250   [1]   VALVE ASS'Y Komatsu 4.542 kg.
    ["SN: 1001-UP"]
10.   17M-61-43180   [1]   PLATE Komatsu China
    ["SN: 1001-UP"]
11.   07000-13032   [1]   O-RING Komatsu China 0.002 kg.
    ["SN: 1001-UP"] analogs:["YM24321000350", "YM24311000320", "0700003032"]
12.   07372-21035   [4]   BOLT Komatsu 0.033 kg.
    ["SN: 1001-UP"]
13.   01643-51032   [4]   WASHER Komatsu 0.17 kg.
    ["SN: 1001-UP"] analogs:["R0164351032"]
14.   02781-00422   [1]   UNION Komatsu 0.11 kg.
    ["SN: 1001-UP"]
15.   07002-12034   [1]   O-RING Komatsu China 0.94 kg.
    ["SN: 1001-UP"] analogs:["0700002034", "0700202034", "0700012034"]
16.   02896-11012   [1]   O-RING Komatsu China 0.17 kg.
    ["SN: 1001-UP"] analogs:["855051014"]
17.   02782-10311   [1]   ELBOW Komatsu 0.1 kg.
    ["SN: 1001-UP"]
18.   07002-11423   [1]   O-RING Komatsu China 0.001 kg.
    ["SN: 1001-UP"] analogs:["0700201423"]
19.   02896-11009   [1]   O-RING Komatsu China 0.01 kg.
    ["SN: 1001-UP"] analogs:["R0289611009", "0286911009"]
20.   02781-0021D   [1]   UNION Komatsu 0.04 kg.
    ["SN: 1001-UP"]
22.   02896-11008   [1]   O-RING Komatsu China 0.12 kg.
    ["SN: 1001-UP"]
26.   01252-61080   [4]   BOLT Komatsu China
    ["SN: 1001-UP"]
28.   02754-00415   [1]   HOSE Komatsu China
    ["SN: 1005-UP"]
28.   02754-00416   [1]   HOSE Komatsu China
    ["SN: 1001-1004"]
31.   07095-10420   [3]   CUSHION Komatsu 0.038 kg.
    ["SN: 1001-UP"]
34.   154-969-7490   [1]   TUBE Komatsu China
    ["SN: 1005-UP"]
34.   154-03-71981   [1]   TUBE Komatsu China
    ["SN: 1001-1004"]
36.   07095-00421   [2]   CUSHION Komatsu 0.042 kg.
    ["SN: 1001-UP"]
40.   02754-00405   [1]   HOSE Komatsu China 1.09 kg.
    ["SN: 1001-UP"]
41.   02764-00304   [1]   HOSE Komatsu China
    ["SN: 1001-UP"]
42.   01597-01009   [12]   NUT Komatsu 0.011 kg.
    ["SN: 1001-UP"]
43.   01643-31032   [12]   WASHER Komatsu 0.054 kg.
    ["SN: 1001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
44.   07283-32236   [6]   CLIP Komatsu 0.076 kg.
    ["SN: 1001-UP"]
45.   154-03-71941   [1]   BRACKET Komatsu China
    ["SN: 1001-UP"]
46.   154-03-71961   [3]   TUBE Komatsu China
    ["SN: 1001-UP"]
47.   154-03-72311   [1]   PLATE Komatsu China
    ["SN: 1001-UP"]
49.   01010-81240   [2]   BOLT Komatsu 0.052 kg.
    ["SN: 1001-UP"] analogs:["801015573", "0101051240"]
