TRACK FRAME (RECOIL SPRING) (R.H.)(#1001-) D85MS-15 S/N 1001-1005 Komatsu


OK request send
CRAWLER LOADERS
D85MS-15 S/N 1001-1005
UNDER CARRIAGE
TRACK FRAME (FRONT IDLER) (R.H.)(#1001-)
TRACK FRAME (FRONT IDLER) (R.H.)(#1001-)
300100
TRACK FRAME (R.H.)(#1001-)
TRACK FRAME (R.H.)(#1001-)
300090
TRACK FRAME (TRACK ROLLER GURAD) (L.H.)(#1001-)
TRACK FRAME (TRACK ROLLER GURAD) (L.H.)(#1001-)
300080
TRACK FRAME (TRACK ROLLER) (SINGLE) (R.H.)(#1001-)
TRACK FRAME (TRACK ROLLER) (SINGLE) (R.H.)(#1001-)
300120
TRACK FRAME (TRACK ROLLER) (DOUBLE) (R.H.)(#1001-)
TRACK FRAME (TRACK ROLLER) (DOUBLE) (R.H.)(#1001-)
300130
TRACK FRAME (CARRIER ROLLER) (R.H.)(#1001-)
TRACK FRAME (CARRIER ROLLER) (R.H.)(#1001-)
300140

TRACK FRAME (RECOIL SPRING) (R.H.)(#1001-)

D85MS-15 S/N 1001-1005
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
34
35
35
36
36
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
1.   154-30-73150   [1]   CYLINDER Komatsu 58 kg.
    ["SN: 1001-UP"]
2.   07177-09040   [1]   BUSHING Komatsu China 0.22 kg.
    ["SN: 1001-UP"] analogs:["7075215620"]
3.   154-30-73130   [1]   SPRING Komatsu 107.35 kg.
    ["SN: 1001-UP"]
4.   154-30-73110   [1]   CABIN Komatsu 48.44 kg.
    ["SN: 1001-UP"]
5.   154-30-73160   [1]   NUT Komatsu 6.56 kg.
    ["SN: 1001-UP"]
7.   207-30-54160   [1]   SEAL Komatsu China 0.053 kg.
    ["SN: 1001-UP"] analogs:["R2073054160"]
8.   154-30-73170   [2]   SPACER Komatsu 0.4 kg.
    ["SN: 1001-UP"]
9.   203-30-42260   [1]   VALVE Komatsu 0.35 kg.
    ["SN: 1001-UP"] analogs:["2013052290", "R2033042260"]
10.   07020-00900   [1]   FITTING Komatsu 0.01 kg.
    ["SN: 1001-UP"] analogs:["0700000900", "M012443000109", "R0702000900"]
11.   14X-30-13174   [1]   PLATE Komatsu 0.09 kg.
    ["SN: 1001-UP"] analogs:["14X3033170"]
12.   01010-80830   [2]   BOLT Komatsu 0.017 kg.
    ["SN: 1001-UP"] analogs:["6735511120", "0101050830", "0737200830", "1240145H1"]
13.   01643-30823   [2]   WASHER Komatsu 0.004 kg.
    ["SN: 1001-UP"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"]
14.   14X-30-13164   [1]   HOLDER Komatsu 12.1 kg.
    ["SN: 1001-UP"]
17.   135-30-14620   [1]   COVER Komatsu 0.46 kg.
    ["SN: 1001-UP"]
18.   01010-81020   [3]   BOLT Komatsu 0.161 kg.
    ["SN: 1001-UP"] analogs:["801014093", "0101051020", "801015108"]
19.   01643-31032   [3]   WASHER Komatsu 0.054 kg.
    ["SN: 1001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
20.   07049-01012   [1]   PLUG Komatsu 0.001 kg.
    ["SN: 1001-UP"]
21.   01010-81240   [4]   BOLT Komatsu 0.052 kg.
    ["SN: 1001-UP"] analogs:["801015573", "0101051240"]
22.   01643-31232   [4]   WASHER Komatsu 0.027 kg.
    ["SN: 1001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
23.   14X-30-13143   [1]   PISTON Komatsu China 37 kg.
    ["SN: 1001-UP"] analogs:["R14X3013143"]
24.   150-30-13442   [1]   PACKING Komatsu China 0.07 kg.
    ["SN: 1001-UP"] analogs:["R1503013442"]
25.   150-30-13480   [1]   RING Komatsu 0.014 kg.
    ["SN: 1001-UP"] analogs:["R1503013480"]
26.   150-30-13460   [1]   RING Komatsu China 0.01 kg.
    ["SN: 1001-UP"] analogs:["R1503013460"]
27.   150-30-13430   [2]   RING Komatsu China 0.016 kg.
    ["SN: 1001-UP"] analogs:["0715500820"]
28.   154-30-71620   [1]   YOKE Komatsu 47.05 kg.
    ["SN: 1001-UP"]
29.   195-30-14151   [1]   WASHER Komatsu 1 kg.
    ["SN: 1001-UP"]
30.   195-30-14160   [1]   PLATE Komatsu 0.05 kg.
    ["SN: 1001-UP"]
31.   01010-82465   [1]   BOLT Komatsu 0.341 kg.
    ["SN: 1001-UP"] analogs:["0101062465", "0101032465", "0101052465"]
32.   01011-82045   [8]   BOLT Komatsu 0.418 kg.
    ["SN: 1001-UP"]
33.   01643-32060   [8]   WASHER Komatsu China 0.044 kg.
    ["SN: 1001-UP"] analogs:["802170007", "0164322045", "0164302045"]
34.   195-30-17960   [4]   PLATE Komatsu China 0.12 kg.
    ["SN: 1001-UP"]
35.   155-30-13230   [4]   SPRING Komatsu China 0.7 kg.
    ["SN: 1001-UP"]
36.   154-30-72720   [2]   GUIDE PLATE ASS'Y Komatsu China
    ["SN: 1001-UP"]
