TRACK FRAME (CARRIER ROLLER) (R.H.)(#1001-) D85MS-15 S/N 1001-1005 Komatsu


OK request send
CRAWLER LOADERS
D85MS-15 S/N 1001-1005
UNDER CARRIAGE
TRACK FRAME (TRACK ROLLER) (DOUBLE) (R.H.)(#1001-)
TRACK FRAME (TRACK ROLLER) (DOUBLE) (R.H.)(#1001-)
300130
TRACK FRAME (TRACK ROLLER) (SINGLE) (R.H.)(#1001-)
TRACK FRAME (TRACK ROLLER) (SINGLE) (R.H.)(#1001-)
300120
TRACK FRAME (RECOIL SPRING) (R.H.)(#1001-)
TRACK FRAME (RECOIL SPRING) (R.H.)(#1001-)
300110
TRACK FRAME (TRACK ROLLER GURAD) (R.H.)(#1001-)
TRACK FRAME (TRACK ROLLER GURAD) (R.H.)(#1001-)
300150

TRACK FRAME (CARRIER ROLLER) (R.H.)(#1001-)

D85MS-15 S/N 1001-1005
1
2
3
3
4
5
6
7
8
9
10
11
12
13
13
14
15
16
17
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
     154-30-01040   [1]   CARRIER ROLLER ASS'Y Komatsu 38.6 kg.
    ["SN: 1001-UP"] analogs:["1543001090"] |$3.
   1.   154-30-25114   [1]   ROLLER Komatsu 25.4 kg.
    ["SN: 1001-UP"]
   2.   154-30-74330   [1]   SHAFT Komatsu China
    ["SN: 1001-UP"]
   3.   06000-30211   [2]   BEARING Komatsu 0.736 kg.
    ["SN: 1001-UP"]
   4.   150-30-14420   [1]   NUT Komatsu China
    ["SN: 1001-UP"] analogs:["1543011790"]
   5.   150-30-14430   [1]   RING Komatsu China
    ["SN: 1001-UP"] analogs:["2083068360"]
   6.   154-30-74350   [1]   COVER Komatsu 1.99 kg.
    ["SN: 1001-UP"]
   7.   07000-12105   [1]   O-RING Komatsu OEM 0.004 kg.
    ["SN: 1001-UP"] analogs:["0700002105"]
   8.   01010-81225   [3]   BOLT Komatsu 0.074 kg.
    ["SN: 1001-UP"] analogs:["01010B1225", "0101051225", "0101051222", "R0101081225"]
   9.   154-30-25220   [1]   COLLAR Komatsu 0.711 kg.
    ["SN: 1001-UP"]
   10.   07000-12125   [1]   O-RING Komatsu OEM 0.005 kg.
    ["SN: 1001-UP"] analogs:["0700002125E", "0700002125"]
   11.   154-30-74370   [1]   PIN Komatsu China
    ["SN: 1001-UP"]
        154-30-00831   [1]   FLOATING SEAL ASS'Y Komatsu China 0.35 kg.
    ["SN: 1001-UP"] analogs:["1543000833", "1503000035", "1543000832", "1543000830"] |$15.
   14.   07052-31624   [1]   PLUG Komatsu 0.076 kg.
    ["SN: 1001-UP"] analogs:["0705211624", "0705221624"]
   15.   154-30-74340   [1]   RING Komatsu China
    ["SN: 1001-UP"]
16.   01010-82080   [4]   BOLT Komatsu 0.262 kg.
    ["SN: 1001-UP"] analogs:["0101052080", "0101032080", "0101062080"]
17.   01643-32060   [4]   WASHER Komatsu China 0.044 kg.
    ["SN: 1001-UP"] analogs:["802170007", "0164322045", "0164302045"]
