TRACK FRAME (TRACK ROLLER GURAD) (R.H.)(#1001-) D85MS-15 S/N 1001-1005 Komatsu


OK request send
CRAWLER LOADERS
D85MS-15 S/N 1001-1005
UNDER CARRIAGE
TRACK FRAME (CARRIER ROLLER) (R.H.)(#1001-)
TRACK FRAME (CARRIER ROLLER) (R.H.)(#1001-)
300140
TRACK FRAME (TRACK ROLLER) (DOUBLE) (R.H.)(#1001-)
TRACK FRAME (TRACK ROLLER) (DOUBLE) (R.H.)(#1001-)
300130
TRACK FRAME (TRACK ROLLER) (SINGLE) (R.H.)(#1001-)
TRACK FRAME (TRACK ROLLER) (SINGLE) (R.H.)(#1001-)
300120

TRACK FRAME (TRACK ROLLER GURAD) (R.H.)(#1001-)

D85MS-15 S/N 1001-1005
1
2
3
4
5
6
7
8
8
9
9
9
9
10
11
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
1.   154-30-71310   [1]   GUARD,L.H. Komatsu 39.03 kg.
    ["SN: 1001-UP"]
2.   154-30-71320   [1]   GUARD,R.H. Komatsu 85 kg.
    ["SN: 1001-UP"]
3.   01010-82255   [10]   BOLT Komatsu 0.246 kg.
    ["SN: 1001-UP"] analogs:["0101052255"]
4.   01643-32260   [10]   WASHER Komatsu China 0.042 kg.
    ["SN: 1001-UP"]
5.   154-30-71390   [5]   SPACER Komatsu 2.24 kg.
    ["SN: 1001-UP"]
6.   154-30-71380   [5]   BOLT Komatsu 1.86 kg.
    ["SN: 1001-UP"]
7.   01580-12218   [5]   NUT Komatsu 0.069 kg.
    ["SN: 1001-UP"]
9.   154-30-71371   [4]   RETAINER Komatsu 3.15 kg.
    ["SN: 1001-UP"]
