COUNTER WEIGHT(#1001-) D85MS-15 S/N 1001-1005 Komatsu


OK request send
CRAWLER LOADERS
D85MS-15 S/N 1001-1005
WORK EQUIPMENT
ROTOR TILT PIPING(#1005-)
ROTOR TILT PIPING(#1005-)
330210
ROTOR TILT PIPING(#1001-1004)
ROTOR TILT PIPING(#1001-1004)
330200
TILT CYLINDER AND BRACE(#1001-)
TILT CYLINDER AND BRACE(#1001-)
330190

COUNTER WEIGHT(#1001-)

D85MS-15 S/N 1001-1005
1
2
3
3
4
4
4
5
5
6
6
6
7
7
8
8
9
9
10
11
12
13
14
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
1.   154-969-2591   [1]   BRACKET Komatsu China
    ["SN: 1001-UP"]
2.   195-69-12121   [20]   WEIGHT Komatsu 157 kg.
    ["SN: 1001-UP"]
3.   195-69-21230   [4]   BOLT Komatsu China
    ["SN: 1001-UP"]
4.   01580-13024   [6]   NUT Komatsu China 0.21 kg.
    ["SN: 1003-UP"]
5.   198-69-11291   [2]   PLATE Komatsu China
    ["SN: 1001-UP"]
6.   01643-33080   [6]   WASHER Komatsu China 0.132 kg.
    ["SN: 1003-UP"]
7.   154-78-14281   [4]   STUD Komatsu China
    ["SN: 1001-UP"] analogs:["1547814280"]
8.   01580-13326   [4]   NUT Komatsu 0.27 kg.
    ["SN: 1001-UP"] analogs:["0158003326"]
9.   01643-33380   [4]   WASHER Komatsu 0.166 kg.
    ["SN: 1001-UP"]
10.   01011-83310   [2]   BOLT Komatsu 1.034 kg.
    ["SN: 1001-UP"] analogs:["0101163310"]
13.   198-71-21880   [6]   BOSS Komatsu 0.52 kg.
    ["SN: 1001-UP"]
14.   154-969-7480   [4]   SPACER,(FOR SHIPPING PARTS) Komatsu China
    ["SN: 1001-UP"]
