FUEL TANK(#20001-) D85PX-15R S/N 20001-20002 Komatsu


OK request send
BULLDOZERS
D85PX-15R S/N 20001-20002
FUEL TANK AND RELATED PARTS
FUEL PIPING(#20001-)
FUEL PIPING(#20001-)
090020
FUEL PIPING (PRE FILTER)(#20001-)
FUEL PIPING (PRE FILTER)(#20001-)
090030

FUEL TANK(#20001-)

D85PX-15R S/N 20001-20002
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
14
15
15
16
16
17
17
18
18
19
20
21
22
23
24
25
26
27
28
28
29
30
31
32
33
34
35
36
37
38
39
40
40
41
42
43
44
45
46
47
47
48
49
50
51
52
53
54
55
56
57
58
59
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
1.   154-04-72112   [1]   TANK Komatsu China
    ["SN: 20001-UP"]
   2.   17A-04-42140   [1]   FILLER Komatsu China
    ["SN: 20001-UP"]
3.   7861-93-4940   [1]   SENSOR Komatsu 0.8 kg.
    ["SN: 20001-UP"]
4.   07000-12085   [1]   O-RING Komatsu China 0.03 kg.
    ["SN: 20001-UP"] analogs:["0700002085", "YM24321000850", "R0700012085"]
5.   01010-81016   [4]   BOLT Komatsu 0.06 kg.
    ["SN: 20001-UP"] analogs:["0101051016"]
6.   01643-31032   [4]   WASHER Komatsu 0.054 kg.
    ["SN: 20001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
7.   17A-04-41411   [1]   CAP Komatsu 5.3 kg.
    ["SN: 20001-UP"]
8.   07056-18422   [1]   STRAINER Komatsu 0.12 kg.
    ["SN: 20001-UP"] analogs:["11Y0411330", "17M0441190"]
9.   22U-60-21520   [1]   BREATHER Komatsu 0.25 kg.
    ["SN: 20001-UP"]
   10.   421-60-35170   [1]   ELEMENT Komatsu 0.032 kg.
    ["SN: 20001-UP"]
   11.   421-60-35180   [1]   COVER Komatsu China
    ["SN: 20001-UP"]
   12.   421-60-35190   [1]   NUT Komatsu China
    ["SN: 20001-UP"]
13.   02781-00311   [2]   UNION Komatsu 0.08 kg.
    ["SN: 20001-UP"]
14.   07002-11423   [2]   O-RING Komatsu China 0.001 kg.
    ["SN: 20001-UP"] analogs:["0700201423"]
15.   02896-11009   [2]   O-RING Komatsu China 0.01 kg.
    ["SN: 20001-UP"] analogs:["R0289611009", "0286911009"]
16.   02782-10420   [2]   ELBOW Komatsu 0.15 kg.
    ["SN: 20001-UP"]
17.   07002-11823   [2]   O-RING Komatsu 0.36 kg.
    ["SN: 20001-UP"] analogs:["0700201823"]
18.   02896-11012   [2]   O-RING Komatsu China 0.17 kg.
    ["SN: 20001-UP"] analogs:["855051014"]
19.   154-04-75152   [1]   JOINT Komatsu China
    ["SN: 20001-UP"]
20.   01010-81230   [2]   BOLT Komatsu 0.043 kg.
    ["SN: 20001-UP"] analogs:["0101051230", "01010B1230"]
21.   01643-31232   [2]   WASHER Komatsu 0.027 kg.
    ["SN: 20001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
     17A-04-41190   [1]   FILTER ASS'Y Komatsu 1.15 kg.
    ["SN: 20001-UP"] |$29.
   22.   14X-04-21660   [1]   CASE Komatsu China
    ["SN: 20001-UP"]
   23.   07002-14234   [1]   O-RING Komatsu China 0.002 kg.
    ["SN: 20001-UP"] analogs:["0700204234"]
   24.   07058-00010   [1]   ELEMENT ASS'Y Komatsu 0.128 kg.
    ["SN: 20001-UP"] analogs:["0705800002"]
25.   01010-80830   [2]   BOLT Komatsu 0.017 kg.
    ["SN: 20001-UP"] analogs:["6735511120", "0101050830", "0737200830", "1240145H1"]
26.   01643-30823   [2]   WASHER Komatsu 0.004 kg.
    ["SN: 20001-UP"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"]
27.   17A-04-41331   [1]   CONNECTOR Komatsu 0.15 kg.
    ["SN: 20001-UP"]
28.   07002-12034   [2]   O-RING Komatsu China 0.94 kg.
    ["SN: 20001-UP"] analogs:["0700002034", "0700202034", "0700012034"]
29.   07700-40460   [1]   VALVE Komatsu 0.228 kg.
    ["SN: 20001-UP"] analogs:["0770020504"]
30.   154-04-75720   [1]   NIPPLE Komatsu China
    ["SN: 20001-UP"]
31.   565-44-15380   [1]   ELBOW Komatsu 0.33 kg.
    ["SN: 20001-UP"]
32.   14X-04-21620   [1]   VALVE Komatsu 0.38 kg.
    ["SN: 20001-UP"]
33.   02782-10516   [1]   ELBOW Komatsu 0.24 kg.
    ["SN: 20001-UP"]
35.   02896-11015   [1]   O-RING Komatsu 0.21 kg.
    ["SN: 20001-UP"] analogs:["21D0969770", "855051016"]
36.   02763-004A4   [1]   HOSE Komatsu 0.478 kg.
    ["SN: 20001-UP"]
37.   154-04-75290   [1]   ELBOW Komatsu China
    ["SN: 20001-UP"]
39.   07270-21550   [1]   TUBE Komatsu China
    ["SN: 20001-UP"]
40.   07281-00197   [2]   CLAMP Komatsu 0.015 kg.
    ["SN: 20001-UP"] analogs:["1950313250"]
41.   04434-52112   [1]   CLIP Komatsu 0.03 kg.
    ["SN: 20001-UP"]
42.   01011-81210   [1]   BOLT Komatsu 0.112 kg.
    ["SN: 20001-UP"] analogs:["801015584", "0101151210"]
44.   581-60-17860   [1]   SPACER Komatsu China
    ["SN: 20001-UP"]
45.   21N-64-36690   [1]   TEE Komatsu 0.28 kg.
    ["SN: 20001-UP"]
48.   02762-00406   [1]   HOSE Komatsu China 0.51 kg.
    ["SN: 20001-UP"]
49.   04434-52712   [1]   CLIP Komatsu 0.036 kg.
    ["SN: 20001-UP"]
50.   07095-20420   [1]   CUSHION Komatsu 0.015 kg.
    ["SN: 20001-UP"]
53.   07285-00155   [1]   CLIP Komatsu 4.8 kg.
    ["SN: 20001-UP"]
54.   07270-01540   [1]   TUBE Komatsu 0.038 kg.
    ["SN: 20001-UP"] analogs:["0727001520"]
55.   17A-04-11191   [6]   PLATE Komatsu 0.58 kg.
    ["SN: 20001-UP"]
56.   01010-81675   [6]   BOLT Komatsu 0.15 kg.
    ["SN: 20001-UP"] analogs:["0101051675", "0101031675", "0101061675"]
57.   01643-31645   [6]   WASHER Komatsu 0.072 kg.
    ["SN: 20001-UP"] analogs:["802170005", "0164301645"]
58.   195-54-42560   [6]   BOSS Komatsu 0.163 kg.
    ["SN: 20001-UP"]
59.   17A-04-41440   [1]   LOCK Komatsu China
    ["SN: 20001-UP"]
