DOZER FRAME(#20001-) D85PX-15R S/N 20001-20002 Komatsu


OK request send
BULLDOZERS
D85PX-15R S/N 20001-20002
WORK EQUIPMENT
DOZER FRAME (BLADE TILT PIPING AND ARM¤ TRUNNION)(#20001-)
DOZER FRAME (BLADE TILT PIPING AND ARM¤ TRUNNION)(#20001-)
330020
TRUNNION(#20001-)
TRUNNION(#20001-)
330030
BLADE(#20001-)
BLADE(#20001-)
330040

DOZER FRAME(#20001-)

D85PX-15R S/N 20001-20002
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
41
42
42
43
43
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
1.   154-929-7310   [1]   FRAME,L.H. Komatsu China
    ["SN: 20001-UP"]
   2.   154-71-71320   [1]   BRACKET (WELDED) Komatsu China
    ["SN: 20001-UP"]
   3.   154-71-71350   [1]   BRACKET,L.H. (WELDED) Komatsu China
    ["SN: 20001-UP"]
   4.   154-71-71731   [1]   BRACKET,L.H. (WELDED) Komatsu China
    ["SN: 20001-UP"]
   5.   154-71-71750   [1]   BRACKET,L.H. (WELDED) Komatsu China
    ["SN: 20001-UP"]
6.   175-71-11482   [1]   CAP Komatsu 18 kg.
    ["SN: 20001-UP"]
7.   175-71-11491   [4]   BOLT Komatsu China 0.72 kg.
    ["SN: 20001-UP"] analogs:["R1757111491"]
8.   175-71-11520   [4]   NUT Komatsu China 0.22 kg.
    ["SN: 20001-UP"] analogs:["R1757111520"]
9.   01643-32260   [4]   WASHER Komatsu China 0.042 kg.
    ["SN: 20001-UP"]
10.   154-71-22470   [1]   PIN Komatsu OEM 5.2 kg.
    ["SN: 20001-UP"]
11.   17A-71-12361   [1]   LOCK Komatsu 0.223 kg.
    ["SN: 20001-UP"]
12.   01010-81635   [2]   BOLT Komatsu 0.088 kg.
    ["SN: 20001-UP"] analogs:["0101061635", "801015185", "0101051635", "0101031635"]
13.   01643-31645   [2]   WASHER Komatsu 0.072 kg.
    ["SN: 20001-UP"] analogs:["802170005", "0164301645"]
14.   154-71-21290   [1]   PIN Komatsu OEM 3.95 kg.
    ["SN: 20001-UP"]
18.   154-71-22261   [1]   JOINT Komatsu China 14.5 kg.
    ["SN: 20001-UP"]
19.   07020-00000   [1]   FITTING,GREASE Komatsu China 0.006 kg.
    ["SN: 20001-UP"] analogs:["YM24761020000", "1756731361", "860010009", "070200000", "R0702000000", "0700000000"]
20.   154-929-7320   [1]   FRAME,R.H. Komatsu China
    ["SN: 20001-UP"]
   22.   154-71-71340   [1]   BRACKET,R.H. (WELDED) Komatsu China
    ["SN: 20001-UP"]
   23.   154-71-71360   [1]   BRACKET,R.H. (WELDED) Komatsu China
    ["SN: 20001-UP"]
   24.   154-71-71760   [1]   BRACKET,R.H. (WELDED) Komatsu China
    ["SN: 20001-UP"]
25.   17A-71-12280   [1]   CAP Komatsu 16 kg.
    ["SN: 20001-UP"]
39.   01010-82490   [8]   BOLT Komatsu China 0.428 kg.
    ["SN: 20001-UP"] analogs:["0101062490", "0101032490", "0101052490"]
40.   01643-32460   [8]   WASHER Komatsu China 0.063 kg.
    ["SN: 20001-UP"] analogs:["R0164332460"]
41.   154-71-71230   [2]   STEP Komatsu China
    ["SN: 20001-UP"]
42.   01010-81240   [8]   BOLT Komatsu 0.052 kg.
    ["SN: 20001-UP"] analogs:["801015573", "0101051240"]
43.   01643-31232   [8]   WASHER Komatsu 0.027 kg.
    ["SN: 20001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
