MARKS AND PLATES (INDONESIAN)(#20001-) D85PX-15R S/N 20001-20002 Komatsu


OK request send
BULLDOZERS
D85PX-15R S/N 20001-20002
MARKS AND PLATES
MARKS AND PLATES (ARABIC) (FOR WITHOUT CAB)(#20001-)
MARKS AND PLATES (ARABIC) (FOR WITHOUT CAB)(#20001-)
360080
MARKS AND PLATES (ARABIC)(#20001-)
MARKS AND PLATES (ARABIC)(#20001-)
360070
MARKS AND PLATES (CHINESE) (FOR WITHOUT CAB)(#20001-)
MARKS AND PLATES (CHINESE) (FOR WITHOUT CAB)(#20001-)
360060
MARKS AND PLATES (INDONESIAN) (FOR WITHOUT CAB)(#20001-)
MARKS AND PLATES (INDONESIAN) (FOR WITHOUT CAB)(#20001-)
360100
MARKS AND PLATES (TURKISH)(#20001-)
MARKS AND PLATES (TURKISH)(#20001-)
360110
MARKS AND PLATES (RUSSIAN)(#20001-)
MARKS AND PLATES (RUSSIAN)(#20001-)
360120

MARKS AND PLATES (INDONESIAN)(#20001-)

D85PX-15R S/N 20001-20002
1
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
25
26
27
27
28
29
29
30
31
32
33
34
35
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
1.   14X-98-11170   [2]   PLATE, OPERATING,LOCK Komatsu 0.005 kg.
    ["SN: 20001-UP"]
2.   09690-F0630   [1]   PLATE, MARK,KOMATSU (FRONT) Komatsu China
    ["SN: 20001-UP"]
3.   17A-98-11180   [1]   PLATE,HORN Komatsu 0.08 kg.
    ["SN: 20001-UP"]
4.   09690-M0063   [1]   PLATE, MARK,KOMATSU Komatsu 0.01 kg.
    ["SN: 20001-UP"]
5.   154-98-75221   [1]   PLATE,OIL CHART Komatsu China
    ["SN: 20003-UP"]
5.   154-98-75220   [1]   PLATE,OIL CHART Komatsu China
    ["SN: 20001-20002"]
6.   154-98-71310   [1]   MARK,D85PX Komatsu China
    ["SN: 20001-UP"]
7.   154-98-71320   [1]   MARK,D85PX Komatsu China
    ["SN: 20001-UP"]
8.   09690-P0630   [2]   PLATE, MARK,KOMATSU Komatsu 0.032 kg.
    ["SN: 20001-UP"]
9.   09690-P1120   [1]   PLATE, MARK,KOMATSU Komatsu 0.132 kg.
    ["SN: 20001-UP"]
10.   154-98-75111   [1]   PLATE,FUSE Komatsu China
    ["SN: 20001-UP"]
11.   154-98-75121   [1]   PLATE,FUSE Komatsu China
    ["SN: 20001-UP"]
12.   154-98-71240   [1]   PLATE,BREAKER Komatsu 0.01 kg.
    ["SN: 20001-UP"]
13.   09602-10001   [1]   PLATE, NAME,(LIMITED SUPPLY) Komatsu China
    ["SN: 20001-UP"]
14.   154-98-75130   [1]   PLATE,MAIN POWER Komatsu China
    ["SN: 20001-UP"]
15.   154-98-75140   [1]   PLATE,ENGINE CONTROLLER Komatsu China
    ["SN: 20001-UP"]
16.   154-98-75151   [1]   PLATE,RIBBON HEATER Komatsu China
    ["SN: 20001-UP"]
17.   154-98-75160   [1]   PLATE,CONTINUOUS PW Komatsu China
    ["SN: 20001-UP"]
18.   09653-A0481   [1]   PLATE, SAFETY,OPERATING OIL TANK Komatsu 0.003 kg.
    ["SN: 20001-UP"]
20.   09654-B0641   [1]   PLATE, SAFETY,LEAVING SEAT Komatsu China
    ["SN: 20001-UP"]
21.   09657-A0881   [2]   PLATE, SAFETY,TRACK ADJUSTING Komatsu 0.011 kg.
    ["SN: 20001-UP"]
22.   09651-A0641   [1]   PLATE, SAFETY,OPERATING AND MAINTENANCE Komatsu China
    ["SN: 20001-UP"]
23.   09659-A057B   [1]   PLATE, SAFETY,ACCUMULATOR Komatsu 0.001 kg.
    ["SN: 20001-UP"]
24.   09667-A0481   [2]   PLATE, SAFETY,REVOLUTION Komatsu 0.001 kg.
    ["SN: 20001-UP"]
25.   09805-C0881   [2]   PLATE, SAFETY,DO NOT STEP Komatsu 0.01 kg.
    ["SN: 20001-UP"]
26.   09806-B1683   [2]   PLATE, SAFETY,KEEP A SAFE DISTANCE Komatsu 0.025 kg.
    ["SN: 20001-UP"]
27.   09808-A0881   [2]   PLATE, SAFETY,BATTERY CABLE Komatsu 0.004 kg.
    ["SN: 20001-UP"]
28.   09963-A1640   [1]   TAG,DO NOT OPERATE Komatsu 0.04 kg.
    ["SN: 20001-UP"]
29.   14X-98-35181   [2]   PLATE,REAR REFLECTOR Komatsu 0.005 kg.
    ["SN: 20001-UP"]
30.   09802-10500   [1]   PLATE, SAFETY,BACKWARD CAUTION Komatsu China
    ["SN: 20001-UP"]
31.   6217-71-6530   [1]   PLATE,FUEL FILTER Komatsu China
    ["SN: 20001-UP"]
32.   09649-00512   [1]   PLATE, INSTRUCTION,ENGINE STOP Komatsu China
    ["SN: 20001-UP"]
33.   09637-05163   [1]   PLATE, INSTRUCTION,AIR CLEANER Komatsu China
    ["SN: 20001-UP"]
34.   09620-B2050   [1]   PLATE,(LIMITED SUPPLY) Komatsu China
    ["SN: 20001-UP"]
35.   09620-C2050   [1]   PLATE,(LIMITED SUPPLY) Komatsu China
    ["SN: 20001-UP"]
