PILOT CHECK VALVE (FOR RIPPER) GD705A-4 S/N 21001-UP Komatsu


OK request send
GRADERS
GD705A-4 S/N 21001-UP
HYDRAULIC SYSTEM
PILOT CHECK VALVE (FOR FRONT BLADE)
PILOT CHECK VALVE (FOR FRONT BLADE)
180460
PILOT CHECK VALVE (FOR SCARIFIER)
PILOT CHECK VALVE (FOR SCARIFIER)
180450
PILOT CHECK VALVE (FOR POWER TILT)(#21037-)
PILOT CHECK VALVE (FOR POWER TILT)(#21037-)
180440
DUAL DEMAND VALVE (D.D.V SPEC)(#23001-)
DUAL DEMAND VALVE (D.D.V SPEC)(#23001-)
180480
DIRECTIONAL CONTROL VALVE (D.D.V SPEC)(#23001-)
DIRECTIONAL CONTROL VALVE (D.D.V SPEC)(#23001-)
180490
FLOW DIVIDER VALVE (D.D.V SPEC)(#23001-)
FLOW DIVIDER VALVE (D.D.V SPEC)(#23001-)
180500

PILOT CHECK VALVE (FOR RIPPER)

GD705A-4 S/N 21001-UP
1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
     234-61-31200   [1]   VALVE ASS'Y,PILOT CHECK Komatsu China
    ["SN: 21001-UP"] |$0.
   1.   232-06-56210   [1]   HOUSING Komatsu China
    ["SN: 21001-UP"]
   2.   232-60-56120   [1]   PLUG Komatsu China
    ["SN: 21001-UP"]
   3.   07002-13334   [1]   O-RING Komatsu China 0.025 kg.
    ["SN: 21001-UP"] analogs:["0700203334"]
   4.   07000-13022   [1]   O-RING Komatsu OEM 0.001 kg.
    ["SN: 21001-UP"] analogs:["0700003022"]
   5.   232-60-56130   [1]   SPOOL Komatsu China
    ["SN: 21001-UP"] analogs:["2326000350", "2326056110", "2326056100", "2326056310", "2326100130"]
   6.   07000-12012   [2]   O-RING Komatsu China 0.001 kg.
    ["SN: 21001-UP"] analogs:["0700002012", "7082E11790"]
   7.   232-60-56140   [1]   BOLT Komatsu China
    ["SN: 21001-UP"]
   8.   01583-12012   [1]   NUT Komatsu 0.04 kg.
    ["SN: 21001-UP"]
   9.   232-60-56150   [1]   COLLAR Komatsu China
    ["SN: 21001-UP"]
   10.   135-60-12152   [1]   VALVE Komatsu 0.038 kg.
    ["SN: 21001-UP"]
   11.   234-60-16240   [1]   SPRING Komatsu China
    ["SN: 21001-UP"] analogs:["2326016240"]
   12.   232-60-16343   [1]   VALVE Komatsu China
    ["SN: 21001-UP"]
   13.   232-60-16430   [1]   SLEEVE Komatsu China
    ["SN: 21001-UP"]
   14.   234-60-16360   [1]   VALVE Komatsu China
    ["SN: 21001-UP"]
   15.   07000-12021   [1]   O-RING Komatsu China 0.01 kg.
    ["SN: 21001-UP"] analogs:["0700002021"]
   16.   07001-02021   [1]   RING,BACK-UP Komatsu 0.061 kg.
    ["SN: 21001-UP"]
   17.   234-60-16350   [1]   SPRING Komatsu China
    ["SN: 21001-UP"]
   18.   232-60-16440   [1]   PLUG Komatsu China
    ["SN: 21001-UP"]
   19.   232-60-16450   [1]   NUT Komatsu China
    ["SN: 21001-UP"]
   20.   07002-13034   [1]   O-RING Komatsu China 0.005 kg.
    ["SN: 21001-UP"] analogs:["0700203034"]
