ROTOR LIFT LINE (COVER AND BRACKET)(#1001-)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 154-969-3673 | [1] | COVER Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 2. | 01010-81230 | [5] | BOLT Komatsu | 0.043 kg. |
| ["SN: 1001-UP"] analogs:["0101051230", "01010B1230"] | ||||
| 3. | 01643-31232 | [5] | WASHER Komatsu | 0.027 kg. |
| ["SN: 1001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 4. | 01010-81260 | [2] | BOLT Komatsu China | 0.069 kg. |
| ["SN: 1001-UP"] analogs:["0101051260"] | ||||
| 6. | 154-969-3161 | [1] | COVER Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 7. | 175-54-34170 | [5] | WASHER Komatsu | 0.03 kg. |
| ["SN: 1001-UP"] | ||||
| 10. | 154-969-3292 | [1] | PLATE Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 11. | 01010-81240 | [2] | BOLT Komatsu | 0.052 kg. |
| ["SN: 1001-UP"] analogs:["801015573", "0101051240"] | ||||
| 13. | 154-969-3722 | [1] | BRACKET Komatsu China | |
| ["SN: 1001-UP"] | ||||
| 14. | 01010-81265 | [2] | BOLT Komatsu | 0.074 kg. |
| ["SN: 1001-UP"] analogs:["0101051265"] | ||||
